feat: add RMSE-guided quantization, AIO GGUF bundling, and lazy-load flag

[shikaku2]

Summary

Three related improvements to the --convert workflow and inference startup, focused on reducing disk footprint, RAM usage during conversion, and VRAM requirements at inference time.

---

1. RMSE-guided mixed-precision quantization (--rmse <threshold>)

Adds a --rmse <pct> flag to convert mode that automatically selects per-tensor quantization types by running a two-pass sweep.

How it works:

• Pass 1: for each tensor, loads it as f32, tests candidate quant types (f16, Q8_0, Q6_K, Q5_1, Q5_0, Q4_K, Q4_0, IQ4_NL, Q3_K, Q2_K) from highest to lowest quality, and records the lowest-quality type that keeps RMSE within the threshold.
• Pass 2: quantizes and writes each tensor at its assigned type.

Peak RAM during conversion = f32 size of the single largest tensor (not the full model). The two-pass design is streaming — no full model is held in memory at once.

Results on SD3.5 Large:

The original model files are all F16/BF16 — no F32 in distribution:

File	Format	Size
sd3.5_large.safetensors	F16 + BF16	16.5 GB
t5xxl_fp16.safetensors	F16	9.8 GB
clip_g.safetensors	F16	1.4 GB
clip_l.safetensors	F16	0.25 GB
Total (4 files)		~27.9 GB

RMSE quantization results (all bundled into a single AIO GGUF):

Target	Size	Reduction
F16 baseline (4 files)	~27.9 GB	—
1% RMSE	~14 GB	−50%
3% RMSE	~13 GB	−53%
6% RMSE	~12 GB	−57%

At 1% RMSE, most tensors land on Q4_K or Q5_K. RMSE is a tensor-level metric, not a perceptual one — see visual comparison below.

---

2. All-in-one GGUF bundling (--convert with multiple component flags)

--convert now accepts separate component files (--clip_l, --clip_g, --t5xxl, --diffusion-model, --llm, --vae) and writes them all into a single output GGUF, including metadata that allows the loader to identify each component.

Before this, distributing a quantized model required shipping 4–6 separate files and passing each as a CLI flag. After, a single .gguf is self-contained and loadable with just -m.

# Before
./sd -m sd3.5_large.safetensors --clip_l clip_l.safetensors --clip_g clip_g.safetensors \
    --t5xxl t5xxl_fp16.safetensors ...

# After (convert once)
./sd --convert --diffusion-model sd3.5_large.safetensors \
    --clip_l clip_l.safetensors --clip_g clip_g.safetensors \
    --t5xxl t5xxl_fp16.safetensors -o sd3.5_large_aio.gguf

# Then run with a single file
./sd -m sd3.5_large_aio.gguf ...

This is convenience packaging — no quality or performance change.

---

3. Lazy-load / staged VRAM eviction (-ll / --lazy-load)

Adds a -ll/--lazy-load flag that enables mmap-backed model loading and staged RAM eviction across the inference pipeline.

Problem: Systems with limited VRAM cannot run the full pipeline when all components (text encoders + diffusion model + VAE) are loaded simultaneously.

How it works:

• Model is loaded via mmap. Pages are only read from disk when accessed.
• After each pipeline stage completes, madvise(MADV_DONTNEED) is called on that component's tensors, releasing physical pages without invalidating pointers.
• Eviction is sequential: text encoders → diffusion model → VAE. Since these stages don't overlap, peak VRAM/RAM is the max of any single component rather than the sum.
• Auto-enables VAE tiling when -ll is active, to avoid a single large allocation. (SD3.5 VAE decode at 1024×1024 would require a ~4.6 GiB VkBuffer which exceeds the Vulkan maxMemoryAllocationSize = 4 GiB hard limit on many GPUs.)

Also applies to --convert: lazy-load + threading reduces peak RAM during quantization significantly — useful for generating quants on machines without large RAM.

This feature is architecture-agnostic (UNet, DiT, Flux, WAN, etc.) and works with both AIO GGUFs and separately-loaded component files.

---

Visual comparison

SD3.5 Large, Seed 42, 1024×1024, 20 steps. Baseline = F16 safetensors with -ll. All RMSE variants are AIO GGUF with -ll. Hardware: RX 9060 XT 16 GB, Vulkan.

"a cute cat"

F16 baseline	1% RMSE	3% RMSE	6% RMSE

"a vintage photograph of an old phonograph sitting on a table"

F16 baseline	1% RMSE	3% RMSE	6% RMSE

"a serene japanese garden with cherry blossoms at sunset"

F16 baseline	1% RMSE	3% RMSE	6% RMSE

---

Testing

• SD3.5 Large at 1024×1024, 20 steps, Vulkan backend (RX 9060 XT 16GB)
• 5 diverse prompts tested with -ll enabled; all succeeded
• VAE tiling: ~3.5s (49 tiles) vs ~65s CPU fallback without tiling
• RMSE conversion tested at 1%, 3%, 6% thresholds on SD3.5 Large

Known limitations / future work

• RMSE threshold tuning is model-dependent; 1% is a reasonable starting point but systematic perceptual quality evaluation would help establish better defaults
• -ll eviction is currently Linux-only (madvise path); Windows/macOS gracefully skip eviction but still benefit from mmap loading
• AIO bundling does not yet validate that bundled components are compatible with each other
